Notice:
Due to the weight of 10kw hydro turbine is about 135kg, shipping by courier, door to door is very expensive.
If you accept sea transportation, rail transportation, land transportation or pick-up at the airport, please contact us for cheap shipping method, the freight will be much cheaper. For example, to European countries, the sea freight is USD50. The transportation time is one month, but the shipping fees is much lower. To seaport in Chile, the shipping fees is about USD80.
Product Description
10KW Turgo turbine generator suit for water head over 25m, flow over 0.035m3/s.
1. Turbine and generator are integrated, which is more easy to install and maintain
2. Hydraulic direct drive generator, without more drive mechanism and efficiency is much higher, Extremely low failure rate.
3. Auto voltage rectifier is installed within generator, the voltage is more stable.
4. Optional single-phase voltage 220-240V or 3-phase voltage 380V-430V. The generator’s unique voltage excitation design, be suitable for provide long-distance voltage transmission.
5. Mainly used in: mountainous water sources sufficient and water head more than 20 meters
|
Model
|
Rated Output
|
Max.Output
|
Voltage / 1 phase / 3-phase
|
Frequency
|
Water head/Altitude
|
Water Flow
|
|
ST-10KW/
STC-10KW
|
10KW
|
11KW
|
220-240V / 380-430V
|
50Hz ± 5%
|
25M-60M
|
0.035 – 0.06（m3/s)
|
Detailed Images
After Sales Service
Warranty Service
1.Our product has guarantee for one year or 1000 hours whichever reach first from ex-factory date.
2.During the guarantee period, our will provide the free easy-damageable spare parts of alternator caused by our quality of production or raw material.
3.After expiration, our provides cost spare parts maintenance of alternator. If engine with international warranty service, the engine product warranty by local authorization Service agent.
